40 L / D Plastic Twin Screw Extruder ABS Plastic Processed Multiple Feed Mode

Minimum Order Quantity :	1 set	Price :	USD 34000-200000
Packaging Details :	Wooden base plate, damp proof plastic lining	Delivery Time :	65-70 work days
Payment Terms :	T/T

Place of Origin:	CHINA	Brand Name:	ADVS
Certification:	ISO9001	Model Number:	HE27

Detail Information
Automatic Grade:	Automatic	Condition:	New
Plastic Processed:	ABS	After-sales Service Provided:	Engineers Available To Service Machinery Overseas
L/d:	40
Highlight:	recycled plastic extruder , plastic extrusion equipment

Product Description

HE27 Plastic Compounder with High Quality are Widely Used around the World

Basic Infromation :

Model NO.	HE 27
Type	Twin Screw Extruder
Plastic Processed	ABS
Product Type	Granulating Extruder
Feeding Mode	Multiple Feed
Assembly Structure	Integral Type Extruder
Screw	Twin-Screw
Engagement System	Full Intermeshing
Screw Channel Structure	Deep Screw
Exhaust	Exhaust
Automation	Automatic
Computerized	Computerized
Trademark	ADVS
Transport Package	wooden base plate,damp proof plastic lining
Specification	screw diameter 27mm
Origin	Si Chuan China

Technical datas of HE27 high standard plastic compounder :

	Screw diameter	L/D	Motor power	Max.Speed	T/A³	Center distance	OD/ID	Output range
HE27	27	40	37	1500	11.3	22.5	1.54	20-120

Configuration feartures of HE27 compounder :

Electrical system : PLC and instrument control for your choice ; control cabinet and power cabinet are seperate , strong and weak

Machine frame : high rigidity whole steel plate welding

Heating medium : heating rod imported from Germany

Material of shaft is imported from Finland

Screw shaft : material of screw element is high wear and corrosion resistant imported from Finland ; the surface of screw elements have done mirror polishing process
